Reflector films - polycarbonate

Makrofol® LM 903

Makrofol® LM 903

Makrofol® LM903 1-4 160008 is an opaque white extruded film based on Makrolon polycarbonate (PC). It offers the high light reflection which is designed to apply in the field of LCD backlight and LED backlight. Makrofol® LM903 1-4 160008 is available in the thicknesses of 300 µm. Other thicknesses are on request. The surface combination is one side gloss and one side matte. The reflector film is offered in rolls and sheets.

AvailabilityArticle Surface Colour Colour Code Width Thickness
429688 FINE MATT/GLOSSY WHITE 160008 1000 0.3

Loading more items...



Polycarbonate reflector films

As a specialist for technical films, the König Film Centre offers you various special films for special applications. These include the polycarbonate reflector film Makrofol LM 903 for ideal and efficient light reflection from the German manufacturer Covestro.

Covestro is a leader in polycarbonate films for lighting applications and the lighting industry. In addition to reflector films, these include light diffusion films and films for directing light.

Properties of our reflective film

The reflective polycarbonate film Makrofol LM 903 1-4 160008 is a white, opaque extrusion film. The opaque film with a high gloss surface offers high light reflection.

Polycarbonate films have high mechanical strength and impact resistance. In addition, they guarantee a distinct temperature resistance from - 40 °C to 130 °C (continuous use temperature of 105 °C). PC films for reflecting light also have high tensile strength and good dielectric properties.

Applications of polycarbonate films for light reflection

Typical applications of light-reflecting polycarbonate films come from the lighting technology or industry. Reflective films are also interesting in the lighting industry, as reflectors significantly increase the efficiency of lamps. Reflective films reflect the available light almost completely back to the viewer.

Processing and use

Polycarbonate films for light reflection can be easily printed. They can also be cut, punched, embossed and glued. Polycarbonate reflective films are suitable for thermoforming and back injection and the insert moulding process (FIM) as well as high pressure forming (HPF). The polycarbonate reflective films we offer can be cold and hot formed.

No special accessories or tools are required for the processing of our PC reflective film.

Consultation and service

Do you have a project in the lighting industry? As a specialist for technical films, we have extensive know-how. We are happy to advise you from the initiation of your project to its subsequent implementation. We will recommend the right film for your project.

We offer our films as rolls and as rectangular sheets in the format you require. Tell us the format you need for your project and we will be happy to send you an offer with an attractive price. Please contact us! We look forward to your enquiry.

If you have any further questions about our reflective films, our range, our manufacturers, our cutting service and any other concerns, we will be happy to advise you.
